Specification
Model: LL0214AMAC
Length(INCH): 11.8", 15.7", 19.7", 35.4", 43.3"
Length(MM): 300mm, 400mm, 500mm, 900mm, 1100mm
CCT: 3000K/3500K/4000K
Efficacy: 70lm/w
PF: ≧0.9
CRI: ≧90
Dimming: 0-10V
Driver: ARCATA or equivalent
LED: Samsung or equivalent
Material: Silicon, Aluminum, Polyester Fiber
Input Voltage: AC120-277V/ AC220-240V
LED Lifetime: >50,000H
Mounting: Pendant, Surface mounted
Package: PE Foam with master carton
Features
◆ Flexible MOQ.
◆ ETL listed, 5 years warranty.
◆ 2 color finishes(black, white), can be customized.
◆ Quite nice craftsmanship.
◆ No dark area, soft and even light distribution.
◆ Acoustic version with 38 acoustic felt colors for option.
◆ 300 degree emmiting versions are available.
◆ Good for use in hotel, office, public building, shopping mall, etc.
◆ The packaging has passed strict tests which is suitable for air shipping.
◆ Packing with single piece per carton is good fit for stock, bulk pack is suitable for ordering per project.
Other Products In The Same Family
| Model No. | Power | Size (mm/inch) | Input Voltage(v) | CRI | CCT (K) | PF | Efficacy (LM/W) | Body Color | Beam (degree) | Installation | Material |
| LL0214AMAC-40W | 40W | 300*300*28/ 11.8*11.8*1.1 | AC120-277V/ AC220-240V | ≧90 | 3000K/ 3500K/ 4000K | ≧0.9 | 70LM/W | White/ Black | 300 | Surface Mounted | Silicon+Alu+polyester fiber |
| LL0214AMAC-50W | 50W | 400*400*28/ 15.7*15.7*1.1 | |||||||||
| LL0214AMAC-72W | 72W | 500*500*28/ 19.7*19.7*1.1 | |||||||||
| LL0214AMAC-100W | 100W | 500*900*28/ 19.7*35.4*1.1 | |||||||||
| LL0214ASAC-150W | 150W | 1100*650*28/ 43.3*25.6*1. |
Download
 |
|
|
|
Client Feedback:
"Thank you for the new data sheet. I am happy to work with you."
