Specification
Model: LL01201S-AC
Diameter(inch): D6.5
Diameter(MM): D165mm
CCT: 3000K/3500K/4000K
Efficacy: 70m/w
PF: ≧0.9
CRI: ≧90
Dimming: 0-10V
Driver: ARCATA or equivalent
LED: Samsung or equivalent
Material: Aluminum, PC, polyester fiber
Input Voltage: AC220-240V / AC120-277V
LED Lifetime: >50,000H
Mounting: Pendant
Package: PE Foam with master carton
Features
◆ Flexible MOQ.
◆ ETL listed, 5 years warranty.
◆ 2 color finishes(black, white), can be customized.
◆ Quite nice craftsmanship, 360deg illuminating for option.
◆ Homogeneous lighting distribution from the bottom lens, reduce noise in the space, offering a better acoustic environment.
◆ Acoustic version with 36 acoustic felt colors for option.
◆ Good for use in hotel, office, home, shop, etc.
◆ The packaging has passed strict tests which is suitable for air shipping.
◆ Packing with single piece per carton is good fit for stock, bulk pack is suitable for ordering per project.
Other Products In The Same Family
| Model No. | Power | Size (mm/inch) | Input Voltage(v) | CRI | CCT (K) | PF | Efficacy (LM/W) | Body Color | Beam (degree) | Installation | Material |
| LL01201S-600-AC | 20W | D165*660 / D6.5*26.0 | AC120-277V / AC220-240 | ≧90 | 3000K/ 3500K/ 4000K | ≧0.9 | 70lm/w | profile in white please advise acoustic color | 360 | 5ft (1.5m) aircraft cable&power cables going to ceiling straight | Alu+PC + polyester fiber |
| LL01201S-900-AC | 30W | D165*1040 / D6.5*41.0 | |||||||||
| LL01201S-1200-AC | 40W | D165*1256 / D6.5*49.8 | |||||||||
| LL01201S-1500-AC | 50W | D165*1645 / D6.5*64.8 | |||||||||
| LL01201S-1800-AC | 60W | D165*1865 / D6.5*73.4 |
