Specification
Model: LL0177S/M-SQ
Profile(W*H): 4.0*4.0"(100*100mm)
Size: 23.6*23.6" up to 47.2*94.5"
(600*600mm up to 1200*2400mm)
CCT: 3000K/3500K/4000K
Efficacy: 105lm/w
PF: ≧0.9
CRI: ≧90
Dimming: non dimmable/0-10v dimming
Driver: ARCATA or equivalent
LED: OSRAM or equivalent
Material: PMMA+Steel
Input Voltage: AC220-240V / AC120-277V
LED Lifetime: >50,000H
Mounting: Pendant, Surface mounted
Features
◆ Flexible MOQ.
◆ 5 years warranty.
◆ Can customize size per reqeust.
◆ Quite nice craftsmanship.
◆ No dark area, soft and even light distribution.
◆ 360 degree full light emitting.
◆ Good for use in hotel, office, public building, shopping mall, etc.
◆ The packaging has passed strict tests which is suitable for air shipping.
◆ Packing with single piece per carton is good fit for stock, bulk pack is suitable for ordering per project.
Other Products In The Same Family
| Model No. | Power | Size (mm/inch) | Input Voltage(v) | CRI | CCT (K) | PF | Efficacy (LM/W) | Body Color | Beam (degree) | Installation | Material |
| LL0177S/M-SQ | 40W | 23.6*23.6"/ 600*600mm | AC220-240V / AC120-277V | ≧90 | 3000K/ 3500K/ 4000K | ≧0.9 | 105lm/w | White | 360 | Suspended/ Surface mounted | PMMA+Steel |
| LL0177S/M-SQ | 60W | 23.6*47.2"/ 600*1200mm | AC220-240V / AC120-277V | ≧90 | 3000K/ 3500K/ 4000K | ≧0.9 | 105lm/w | White | 360 | Suspended/ Surface mounted | PMMA+Steel |
| LL0177S/M-SQ | 80W | 47.2*47.2"/ 1200*1200mm | AC220-240V / AC120-277V | ≧90 | 3000K/ 3500K/ 4000K | ≧0.9 | 105lm/w | White | 360 | Suspended/ Surface mounted | PMMA+Steel |
| LL0177S/M-SQ | 120W | 47.2*94.5"/ 1200*2400mm | AC220-240V / AC120-277V | ≧90 | 3000K/ 3500K/ 4000K | ≧0.9 | 105lm/w | White | 360 | Suspended/ Surface mounted | PMMA+Steel |
