Specification
Model: LL0186UDS
Diameter(INCH): 18.9", 23.6", 35.4", 47.2"
Diameter(MM): 480mm, 600mm, 900mm, 1200mm
CCT: 3000K/3500K/4000K
Efficacy: 85lm/w
PF: ≧0.9
CRI: ≧90
Dimming: 0-10V
Driver: ARCATA or equivalent
LED: Samsung or equivalent
Material: Aluminum, PC
Input Voltage: AC220-240V / AC120-277V
LED Lifetime: >50,000H
Mounting: Pendant, Surface mounted
Package: PE Foam with master carton
Features
◆ Flexible MOQ.
◆ ETL listed, 5 years warranty.
◆ 2 color finishes(black, white), can be customized.
◆ Quite nice craftsmanship.
◆ No dark area, soft and even light distribution.
◆ available in multiple sizes, mountings, and light distributions to fit the scale, proportions and light output requirements of the project.
◆ Acoustic version with 38 acoustic felt colors for option.
◆ Good for use in hotel, office, public building, shopping mall, etc.
◆ The packaging has passed strict tests which is suitable for air shipping.
◆ Packing with single piece per carton is good fit for stock, bulk pack is suitable for ordering per project.
Other Products In The Same Family
| Model No. | Power | Size (mm/inch) | Input Voltage(v) | CRI | CCT (K) | PF | Efficacy (LM/W) | Body Color | Beam (degree) | Installation | Material |
LL0186UDS-50W (up 15w, down 35w) | 50W | 480*416*80(ID480) / 18.9*16.4*3.1(ID18.9) | AC120-277V/ AC220-240V | ≧90 | 3000K/ 3500K/ 4000K | ≧0.9 | 85lm/w | White/ black | 120*2 | central canopy suspended with 5ft (1.5m) safety cables&power cables; | Alu+PC |
LL0186UDS-80W (up 24w, down 56w) | 80W | 600*520*80(ID600) / 23.6*20.5*3.1(ID23.6) | |||||||||
LL0186UDS-120W (up 36w, down 84w) | 120W | 900*780*80(ID900) / 35.4*30.7*3.1(ID35.4) | |||||||||
LL0186UDS-220W (up 66w, down 154w) | 220W | 1200*1040*80(ID1200) / 47.2*40.9*3.1(ID47.2) |
