LL0186S
Specification
Model: LL0186S
Diameter(INCH): 18.9", 23.6", 35.4", 47.2"
Diameter(MM): 480mm, 600mm, 900mm, 1200mm
CCT: 3000K/3500K/4000K
Efficacy: 85lm/w
PF: ≧0.9
CRI: ≧90
Dimming: 0-10V dimming / non-dimmable
Driver: ARCATA or equivalent
LED: Samsung or equivalent
Material: Aluminum, PC
Input Voltage: AC220-240V / AC120-277V
LED Lifetime: >50,000H
Mounting: Pendant, Surface mounted
Package: PE Foam with master carton
Features
◆ Flexible MOQ.
◆ ETL listed, 5 years warranty.
◆ 2 color finishes(black, white), can be customized.
◆ Quite nice craftsmanship.
◆ No dark area, soft and even light distribution.
◆ Acoustic version with 38 acoustic felt colors for option.
◆ Direct, direct/indirect emmiting versions are available.
◆ Good for use in hotel, office, public building, shopping mall, etc.
◆ The packaging has passed strict tests which is suitable for air shipping.
◆ Packing with single piece per carton is good fit for stock, bulk pack is suitable for ordering per project.
Other Products In The Same Family
| Model No. | Power | Size (mm/inch) | Input Voltage(v) | CRI | CCT (K) | PF | Efficacy (LM/W) | Body Color | Beam (degree) | Installation | Material |
| LL0186S-25W | 25W | 480*416*80 / 18.9*16.4*3.1 | AC220-240V / AC120-277V | ≧90 | 3000K/ 3500K/ 4000K | ≧0.9 | 85lm/w | White / black | 120 | central canopy suspended with 5ft(1.5m) aircraft cable&power cables | Alu+PC |
| LL0186S-40W | 40W | 600*520*80 / 23.6*20.5*3.1 | |||||||||
| LL0186S-90W | 90W | 900*780*80 / 35.4*30.7*3.1 | |||||||||
| LL0186S-180W | 180W | 1200*1040*80 / 47.2*40.9*3.1 |
Client Feedback:
"That is great news and I really appreciate how quickly the order had been manufactured."
