Specification
Model: LL0185M
Diameter(inch): 18.9*18.9/23.6*23.6/35.4*35.4/47.2*47.2"
Diameter(MM): 480*480/600*600/900*900/1200*1200mm
CCT: 3000K/3500K/4000K
Efficacy: 85lm/w
PF: ≧0.9
CRI: ≧90
Dimming: 0-10V
Driver: ARCATA or equivalent
LED: Samsung or equivalent
Material: Aluminum, PC
Input Voltage: AC220-240V / AC120-277V
LED Lifetime: >50,000H
Mounting: Surface mounted
Package: PE Foam with master carton
Features
◆ Flexible MOQ.
◆ ETL listed, 5 years warranty.
◆ 2 color finishes(black, white), can be customized
◆ Quite nice craftsmanship, 4 sizes to choose from ranging from 11.8" ” to 47.2”
◆ Even lighting distribution
◆ Good for use in hotel, office, public building, shopping mall, etc.
◆ The packaging has passed strict tests which is suitable for air shipping.
◆ Packing with single piece per carton is good fit for stock, bulk pack is suitable for ordering per project.
Other Products In The Same Family
| Model No. | Power | Size (mm/inch) | Input Voltage(v) | CRI | CCT (K) | PF | Efficacy (LM/W) | Body Color | Beam (degree) | Installation | Material |
| LL0185M-25W | 25W | 480*480*95 / 18.9*18.9*3.7 | AC120-277V/ AC220-240V | ≧90 | 3000K/ 3500K/ 4000K | ≧0.9 | 85lm/w | White/ black | 120 | surface mounted | Alu+PC |
| LL0185M-40W | 40W | 600*600*95 / 23.6*23.6*3.7 | |||||||||
| LL0185M-90W | 90W | 900*900*95 / 35.4*35.4*3.7 | |||||||||
| LL0185M-180W | 180W | 1200*1200*95 / 47.2*47.2*3.7 |
Download
 |
|
|
|
Client Feedback:
"thank you Becky, you are the best to work with"
