LED Acoustic Round Pendant Lights LL0112S-AC FIN

Moon Light acoustic comes with many fins of acoustic felt for great performance of sound aborption, drum shape is great for meeting room, airport, hotel and wide open spaces. Available in multiple diameter sizes from 23.6" up to 47.2"; suspended (aircraft cable and stem for optional) for large room with a high ceiling. Light distributions to fit the scale, proportions and light output requirements of the project.
Mark:
Standard Finish:
Customized Finish:
SKU:
Availability:

PDF Export

facebook sharing button
twitter sharing button
linkedin sharing button
whatsapp sharing button
wechat sharing button
sharethis sharing button


Specification


Model: LL0112S-AC FIN

Diameter(inch): D28/D39/D51"

Diameter(MM): D700/1000/1300mm

CCT: 3000K/3500K/4000K

Efficacy: 85lm/w

PF: ≧0.9

CRI: ≧90

Dimming: 0-10V

Driver: ARCATA or equivalent

LED: Samsung or equivalent

Material: Aluminum, PC, polyester fiber

Input Voltage: AC220-240V / AC120-277V

LED Lifetime: >50,000H

Mounting: Pendant

Package: PE Foam with master carton

Features


 Flexible MOQ.

 ETL listed, 5 years warranty.

 2 color finishes(black, white), can be customized.

 Quite nice craftsmanship, available in a range of diameters from D700mm/D27.5" to D1300mm/D51.2" with 2 heights for options.

 Homogeneous lighting distribution from the bottom lens, reduce noise in the space, offering a better acoustic environment.

 Acoustic version with 36 acoustic felt colors for option.

 Good for use in hotel, office, public building, shopping mall, etc.

 The packaging has passed strict tests which is suitable for air shipping.

 Packing with single piece per carton is good fit for stock, bulk pack is suitable for ordering per project.


Other Products In The Same Family

Model No. Power Size (mm/inch) Input Voltage(v) CRI CCT
(K)
PF Efficacy
(LM/W)
Body Color Beam (degree) Installation Material
LL0112S-40W-AC FIN-D28H12 40W D480*300 / D18.9*11.8

AC120-277V

/

AC220-240

≧90 3000K/
3500K/
4000K
≧0.9 85lm/w profile in white please advise acoustic color 120 5ft (1.5m) aircraft cable&power cables going to ceiling straight Alu+PC +
polyester fiber
LL0112S-40W-AC FIN-D28H24 D480*600 / D18.9*23.6
LL0112S-90W-AC FIN-D39H12 90W D600*300 / D23.6*11.8
LL0112S-90W-AC FIN-D39H24 D600*600 / D23.6*23.6
LL0112S-180W-AC FIN-D51H12 180W D1200*300 / D47.2*11.8
LL0112S-180W-AC FIN-D51H24 D1200*600 / 47.2*23.6



Download

Data Sheet

Data Sheet

Catalogue

Catalogue

Installation

Installation

IES Files

IES Files
