Specification
Model: LLL01201S
Length(inch): 30.2", 47.2", 59.1", 71.5", 94.5"
Length(mm): 766mm, 1200mm, 1500mm, 1815mm, 2400mm
CCT: 3000K/3500K/4000K
Efficacy: 105lm/w
PF: ≧0.9
CRI: ≧90
Dimming: 0-10v dimming
Driver: ARCATA or equivalent
LED: Samsung or equivalent
Material: PC+ Alu
Input Voltage: AC220-240V / AC120-277V
LED Lifetime: >50,000H
Mounting: Pendant
Package: PE Foam with master carton
Features
◆ Flexible MOQ.
◆ 5 years warranty.
◆ Tube dia: D2.4"(60mm)
◆ Quite nice craftsmanship.
◆ No dark area, soft and even light distribution.
◆ 360 deg full light emitting.
◆ The diffuser is always milk white, and small alu profile in anodized color.
◆ Good for use in hotel, office, public building, shopping mall, etc.
◆ The packaging has passed strict tests which is suitable for air shipping.
◆ Packing with single piece per carton is good fit for stock, bulk pack is suitable for ordering per project.
Other Products In The Same Family
Model No. | Power | Size (mm/inch) | Input Voltage(v) | CRI | CCT (K) | PF | Efficacy (LM/W) | Body Color | Beam (degree) | Installation | Material |
LL01201S-766 | 25W | 766*60 / 30.2*2.4 | AC220-240V / AC120-277V | ≧90 | 3000K/ 3500K/ 4000K | ≧0.9 | 105lm/w | White | 360 | suspended with 1.5m power cable and aircraft cable | PC + Alu |
LL01201S-1200 | 40W | 1200*60 / 47.2*2.4 | |||||||||
LL01201S-1500 | 50W | 150060 / 59.1*2.4 | |||||||||
LL01201S-1815 | 60W | 1815*60 / 71.5*2.4 | |||||||||
LL01201S-2400 | 80W | 2400*60 / 94.5*2.4 |
Download
![]() |
Client Feedback:
"We really are very happy.... have a very good finish of metalic housing and difusor.Thanks!!"
